VersaFlo® Recirculation Pump, 3/4 hp, 120 VAC, 1 ph, Bronze
PartGRUUPS32160B
MFG96402739
Description
Grundfos, 96402739, Circulator Pump, Canned Rotor, Series: UPS, 52.5 ft Maximum Head, 625 W Power, 115 VAC, 5.5 to 5.8 A, 60 Hz Frequency, 1 ph, 145 psi Maximum, 3450 rpm Motor, 304 Stainless Steel Impeller, 140 deg F, IPX4D Enclosure, Ceramic Radial/Carbon Thrust Bearing, 12-1/16 in W x 13-1/2 in H Dimensions
Price/Availability Accessible On Login
- Maintenance-free
- Low noise and low energy
- Complete range and wide range of accessories
- Stainless steel rotor can, bearing plate and rotor cladding
- Aluminum alloy stator housing
- Stator with built-in thermal switch
- Non-electronically controlled circulator pumps for domestic building with speed control
- 1-1/2 in Non ANSI 2 bolt with (2) 1/2 in Dia holes
- Flange pipe connection
- Bronze pump housing
- Large stator
- 3-speed motor
UPS pumps constitute a complete range of 3-speed circulator pumps, available both in 50 and 60 Hz. The pumps can be used in both open and closed systems. UPS pumps are of the canned rotor type, i.e. pump and motor form an integral unit without a shaft seal and with only two gaskets for sealing. The bearings are lubricated by the pumped liquid.
| Power Rating | 3/4 hp |
| Voltage Rating | 120 VAC |
| Phase | 1 ph |
| Material | Bronze |
| Series | VersaFlo® |
| Amperage Rating | 5.5 to 5.8 A |
| Bearing Type | Ceramic Radial/Carbon Thrust |
| Dimensions | 12-1/16 in W x 13-1/2 in H |
| Enclosure Type | IPX4D |
| Frequency Rating | 60 Hz |
| Horsepower | 3/4 hp |
| Impeller Type | AISI 304 Stainless Steel |
| Maximum Head | 52.5 ft |
| Maximum Pressure | 145 psi |
| Motor Speed | 3450 rpm |
| Temperature Rating | 140 deg F |
| Type | Canned Rotor |
| Brand | Grundfos |
| UNSPSC | 40151504 |
| Alternate Part Number 1 | UPS32-160FB |
| Manufacturer | Grundfos |
| UPC | 5700390679637 |
| Manufacturer Part Number | 96402739 |
84Z04955 1-Phase Motor
cUL Listed
1 and 2-Pipe Heating Systems, Main Pumps, Zone Pumps, Boiler Shunt Pumps, Pumps for Heating Surfaces, Calorifiers, Underfloor Heating Systems, Solar Heating Systems, Heat Pump Systems, Geothermal Heating Systems, Heat Recovery Systems, 2-Pipe Air-Conditioning Systems and Pumps for Refrigeration Units
