1-Piece Ball Valve, 2 in, Press, Full Port, Stainless Steel Ball, Bronze
PartPPRBVST2
MFG79948
Description
ProPress® Ball Valve, 2-Piece, Series: 2971.3ZL, 2 in Nominal, Press, 250 psi, 0 to 250 deg F, Full Port, Media: Water, Locking Handle Actuator, 316 Stainless Steel Ball, 3.32 in Top to Inlet Center, C87700 Bronze Body, 316 Stainless Steel/PTFE Trim, EPDM, Import
Price/Availability Accessible On Login
- Multiple system and connection solutions
- 316 stainless steel ball
- Smart Connect® technology
- Installs within minutes - up to 80% faster than conventional methods
- Same tool used for installation of ball valves and fittings
- No flame, fire watch or hot work permits required
- PTFE seat/316 stainless steel stem
- EPDM seal
The two-piece zero lead bronze ball valve is equipped with a full port, zero lead bronze body. The ball valve features EPDM sealing elements, EPDM stem seals and Viega Smart Connect® technology for easy identification of unpressed connections during pressure testing.
| Nominal Size | 2 in |
| End Style | Press |
| Port Type | Full |
| Construction | 1-Piece |
| Material | Bronze |
| Ball Material | Stainless Steel |
| Actuator Type | Locking Handle |
| Body Material | C87700 Bronze |
| Domestic/Import | Import |
| Media | Water |
| Pressure Rating | 250 psi |
| Series | 2971.3ZL |
| Softgoods Material | EPDM |
| Temperature Rating | 0 to 250 deg F |
| Top to Inlet Center | 3.32 in |
| Trim Material | 316 Stainless Steel/PTFE |
| Brand | ProPress® |
| Package Width | 4.95 in |
| Package Height | 3.27 in |
| UNSPSC | 40141607 |
| Alternate Part Number 1 | 641401 |
| Package Length | 9.6 in |
| Country of Origin | DE |
| Manufacturer | Viega |
| UPC | 691514799483 |
| Manufacturer Part Number | 79948 |
EPDM Sealing Element and Locking Metal Handle
2 Years Limited
IAPMO/ANSI Z1157|MSS SP-110|NSF 61-372/61-G|UPC Listed
Potable Water Applications
