L Valved Manifold, 8 1/2 in Outlets 1 in Inlets, Brass/Copper

WIRLF2500800 MFG #: LF2500800
Uponor Valved Manifold, L, 8 Outlets, 1/2 in Outlet, 1 in Inlet, 150 psi, 210 deg F, Brass/Copper
  • Application
  • Brand
  • Invoice Description
  • Item Features
  • Manufacturer
  • Manufacturer Part Number
  • Standards / Approvals
  • Web
  • Package Weight
  • Package Dimensions
  • Compliance
PEX-a Plumbing Systems
Uponor
MANIFOLD VLV 8 1/2IN 1IN CU/BRS 150PSI L
320 deg F at no pressure|10.2 gpm at 4 fps|12.8 gpm at 5 fps|Use any product designed to mount 1 in copper pipe as a mounting bracket|Any bend within 6 inches of the ProPEX connection to the manifold requires the use of a Tube Talon (F7050750) or Bend Support (A5110500 and A5150500)|Type L copper, C69300 brass material|ProPEX tool is required, ProPEX rings sold separately, This manifold is not intended for applications using glycol.|Lead free brass
Uponor
LF2500800
ANSI/NSF 14/61|Annex G|ASTM F877/F1960|CAN/CSA B137.5|ICC ESR 1099|IAPMO Listed|UL 1821|ULC/ORD - C 199P|U.P. Code
PEX Fittings
3.38 lb
H: 2 in x W: 4.75 in x L: 14 in
Lead Law Compliant
